Basic Concepts
22
TDS 200-Series Digital Oscilloscope User Manual
Using Autoset
The Autoset function obtains a stable waveform display for you. It
automatically adjusts the vertical and horizontal scaling, as well as
the trigger coupling, type, position, slope, level, and mode settings.
Saving a Setup
By default, the oscilloscope saves the setup each time it is powered
off. The oscilloscope automatically recalls this setup the next time it
is powered on.
NOTE. You should wait at least five seconds after your last change to
the setup before you turn off the power. This ensures that the setup is
saved properly.
You can also permanently save up to five setups in the memory of
the oscilloscope and overwrite setups as needed.
Recalling a Setup
The oscilloscope can recall any of the saved setups or the factory
default setup.
Defaults (Factory Setup)
The oscilloscope is set up for normal operation when it is shipped
from the factory. You can recall the factory default setup any time
you want to operate the oscilloscope using or starting from the
factory default settings.
