Tektronix TDS 200-Series User Manual

TDS 200-Series Digital Oscilloscope User Manual
65
Reference
This section describes the menus and operating details associated with
each front-panel menu button.
Reference Topic Page
Acquire 66
Autoset 70
Cursor 71
Display 72
Hard copy 90
Horizontal controls 74
Math 76
Measure 79
Save/Recall 81
Trigger controls 83
Utility 87
Vertical controls 89

Tektronix TDS 200-Series Specifications

General

Channels	2 or 4
Record Length	2.5k points
Input Coupling	AC, DC, GND
Sample Rate	1 GS/s
Display	5.7-inch monochrome LCD
Vertical Resolution	8-bit
Trigger Modes	Edge, Video, Pulse
Connectivity	USB, RS-232
Power Supply	100 to 240 VAC, 45 to 440 Hz
