Tektronix TDS 200-Series User Manual

Reference
70
TDS 200-Series Digital Oscilloscope User Manual
Autoset
The Autoset feature automatically adjusts the controls to produce a
usable display of the input signal.
Pushing AUTOSET adjusts or sets each of the following items listed.
Function Setting
Acquire mode Adjusted to Sample or Peak Detect
Vertical coupling DC (if GND was selected)
Vertical VOLTS/DIV Adjusted
Bandwidth Full
Horizontal position Centered
Horizontal SEC/DIV Adjusted
Trigger type Edge
Trigger source Lowest numbered channel displayed
Trigger coupling Adjusted to DC, Noise Reject, or
HF Reject
Trigger slope Rising
Trigger holdoff Minimum
Trigger level Set to 50%
Display format YT
Trigger mode Auto
