Reference

TDS 200-Series Digital Oscilloscope User Manual

Math

Although you access the Math menu in the same way, the menu

boxes vary, depending on the oscilloscope model, firmware version,

and installed module.

Push the MATH MENU button to display the waveform math

operations. Push the MATH MENU button again to turn off the math

waveform display. Refer to page 89 for vertical system descriptions.

The following tables list menu boxes available based on the

oscilloscope model, firmware version, and installed module.

TDS 210 and TDS 220 (Firmware V 2.00 and Above), and TDS 224

(All Versions) Oscilloscopes

Operation

Menu Settings Comments

–

(subtraction)

CH1 – CH2 The channel 2 waveform is sub-

tracted from the channel 1 waveform

CH2 – CH1 The channel 1 waveform is sub-

tracted from the channel 2 waveform

CH3 – CH4* The channel 4 waveform is sub-

tracted from the channel 3 waveform

CH4 – CH3* The channel 3 waveform is sub-

tracted from the channel 4 waveform

CH1 + CH2 Channels 1 and 2 are added together

(addition)

CH3 + CH4*

Channels 3 and 4 are added together

* Only available on the TDS 224 oscilloscope.

NOTE. The optional TDS2MM measurement extension module adds

the FFT feature to the oscilloscope. See the TDS 200–Series

Extension Modules Instructions Manual.
