Application Examples
TDS 200-Series Digital Oscilloscope User Manual
53
Triggering on a Video Signal
You are testing the video circuit in a piece of medical equipment and
need to display the video output signal. The video output is an NTSC
standard signal. Use the video trigger to obtain a stable display.
CH 1
75 W terminator
