Operating Basics
24
TDS 200-Series Digital Oscilloscope User Manual
Display Area
In addition to displaying waveforms, the display is filled with many
details about the waveform and the instrument control settings.
Pos:-11.30ms
Ch1 500mV
Trig'd
750mVCh1W 100msM 500msCh2 200mV
12 43
67891011
13
5
12
1. Icon display shows acquisition mode.
Sample mode
Peak detect mode
Average mode
