Temptronic ThermoStream TP04300 Series User Manual

. . . . .
SYSTEM OPERATION
Copy/Delete a Datalog file
TP04300 Series Interface & Applications Manual 3-53
Copy/Delete a Datalog file
Copy/Delete Datalog
Detailed
Field/Button
Descriptions
A
B
C
D
E
F
12
L
K
G
H
I
J
Copy/Delete Datalogs Screen: Fields, Buttons
1 REFRESH LISTINGS: press to update X-Stream and Floppy filenames listed
2 DONE: press to exit back to Datalog Screen
X-STREAM
A Filenames pane (lists all Datalog files); use scroll bar to right to scroll list up/
down
B Highlighted Datalog filename: press Delete (item "E") or Copy (item "F") to do
so
C FREE SPACE kilobytes (system supplied): unused X-Stream memory
available
D FILE SIZE (kilobytes) (system supplied): size of Highlighted Datalog (see item
"B")
E DELETE X-STREAM FILE: press to delete Highlighted Datalog (see item
"B")
F COPY X-STREAM FILE: press to copy Highlighted Datalog (item "B") to
Floppy Disk
FLOPPY DISKETTE
G Highlighted Datalog filename: press Delete (item "K") or Copy (item "L") to do
so
H Filenames pane (lists all Datalog files); use scroll bar to right to scroll list up/
down
