Toro Groundsmaster 360 Service Manual

PrimingtheHydraulicPumps(continued)
g035022
Figure60
1.Startermotor
3.B+terminal
2.Startersolenoid
Note:AbluewireconnectstothestartermotorsolenoidB+terminal(Figure
60).Itisnotnecessarytoremovethisbluewirefromthesolenoidterminal
forhydraulicpumppriming.
3.Connecttheremotestarterswitchelectricalleadstothestartermotor
solenoidB+terminalandpositivepostofthebattery.
4.Engagetheremotestarterswitchandcrankthestarterfor30secondsto
primethehydraulicpumps.Waitfor30secondstoallowthestartermotorand
startersolenoidtocool.Repeatthecrankingprocedureforthesecondtime.
5.Disconnecttheremotestarterswitchleadsfromthestartermotorsolenoid
terminalandpositivepostofthebattery.
FlushingtheHydraulicSystem
IMPORTANT
Flushthehydraulicsystemwheneverthereisaseverecomponent
failureorthesystemiscontaminated(forexample,theuidappears
milky,black,orcontainsmetalparticles).
IMPORTANT
Ifacomponentfailureoccursinthetractioncircuit;refertothe
TractionCircuitComponentFailure(page4–6)forinformation
regardingtheimportanceofremovingcontaminationfromthe
tractioncircuit.
1.Ensurethatthehydraulicuidisatnormaloperatingtemperatureby
operatingthemachineforatleast20minutes.
HydraulicSystem:ServiceandRepairs
Page4–70
Groundsmaster360
16225SLRevC
