WorkLightSwitch(MachineswithOperatorCab–Optional)

g186594

Figure220

1.Worklightswitch(optional)3.Cabheadliner(lightsswitchpanel)

2.Beaconswitch(optional)

g037935

Figure221

Theswitchesarelocatedinthecabheadliner(Figure220).Theswitchesare

usedtoturntheoptionallightkitsonandoff.

TestingtheWorkLightSwitch

1.Parkthemachineonalevelsurface,lowerthecuttingdeck,andshutoffthe

engine.Removethekeyfromthekeyswitch.

2.Toaccesstheswitch,removetheroofpanelfromthetopofthecab;referto

RoofAssembly(page8–10).

3.Removethelightsswitchpanelfromthecabheadliner.

4.Disconnectthemachinewireharnessconnectorfromtheswitchthatyou

aretesting.

5.TheswitchterminalsareidentiedinFigure221andthecircuitryofthe

switchisshownintheCircuitLogicTable(page5–77).Withtheuseofa

multimeter(ohmssetting),testtheswitchfunctionstodetermineifcontinuity

existsbetweenthevariousterminalsforeachswitchposition.Checkthe

continuitybetweentheswitchterminals.

CircuitLogicTable

SwitchPositionClosedCircuitsOpenCircuits

OFF

2+1and5+42+3and5+6

2+3and5+62+1and5+4

Groundsmaster360

Page5–77

ElectricalSystem:TestingtheElectricalComponents

16225SLRevC
