ServicingtheSteeringCylinder

g036464

Figure148

1.Externalcollar(2each)

6.Rollpin11.Rearhead

2.Dustseal(2each)7.O-ring

12.Frontrod

3.Headseal(2each)

8.Pistonseal13.Pistonassembly

4.Back-upring(2each)

9.Wearring

14.Rearrod

5.O-ring(2each)

10.Barrelassembly15.Fronthead

Note:ThefrontandrearsteeringcylindersusedontheGroundsmaster360are

thesameandusethesameserviceprocedures.

Note:Thefollowingproceduresassumetherodendandballjointhavebeen

removedfromthesteeringcylinder;refertoRemovingtheSteeringCylinder

(page4–150).

DisassemblingtheSteeringCylinder

1.Slowlypumpthecylinderrodtoremovethehydraulicuidfromthesteering

cylinderintoadrainpan.Plugboththeportsandcleantheoutersurfaceof

thecylinder.

IMPORTANT

Whenyouclampthesteeringcylinderinavise,clampthebarrel

clevisonlytopreventdamage.Donotclosetheviseonthebarrel

orrod.

Groundsmaster360

Page4–153

HydraulicSystem:ServiceandRepairs

16225SLRevC
