IdlerAssembly
g033711
Figure304
1.Cuttingdeck
10.Drivebelt
19.Idlerspacer(2each)
2.Flatwasher11.Idlerpulley
20.Leftidlerarm
3.Leftspindleassembly
12.Idlerpulley
21.Stopbolt
4.Drivebelt
13.Centerspindleassembly22.Jamnut(2each)
5.Snapring(2each)
14.Rightspindleassembly
23.Doublerring(3each)
6.Flangebushing
15.Socket-headscrew(2each)24.Flangenut(24each)
7.T orsionspring(2each)16.Locknut(2each)25.Ribbedneckbolt(24each)
8.Washer(2each)
17.Rightidlerarm
9.Greasetting(2each)
18.Drivepulley
CuttingDeck:ServiceandRepairs
Page7–6
Groundsmaster360
16225SLRevC
