GeneralInformation
TheOperatorsManualprovidesinformationregardingtheoperation,general
maintenance,andmaintenanceintervalsforyourmachine.Refertothe
Operator’sManualforadditionalinformationwhenservicingthemachine.
ElectricalSchematicsandDiagrams
RefertotheElectricalSchematicsandWireHarnessDrawings/Diagramsin
AppendixA(pageA–1)—FoldoutDrawings.
ToroElectronicController(TEC)
TheGroundsmaster360machinesuseaToroElectronicController(TEC)to
managethemachineelectricalfunctions.Thecontrollerusesmicroprocessor
controlledthatsensestheconditionofvariousswitches(inputs)anddirects
electricalpowertocontroltheappropriatemachinefunctions(outputs)based
ontheinputs.Thestatusofinputstothecontrolleraswellasoutputsfromthe
controllercanbemonitoredwiththeInfoCenterdisplay.
TheTECisattachedtothemachineunderthepowercentercoverbehindthe
operatorseat.
Note:OptionalkitsfortheGroundsmaster360areavailablethatmayrequire
theuseofanadditionalTEC.Eventhoughtheadditionalcontrollerappears
identicaltothestandardcontroller,theyaredifferentintermsoftheconnectors
andinternalhardware.The2controllerscannotbeinterchanged.
IMPORTANT
Beforeperforminganyweldingonthemachine,dothefollowingto
preventdamagingtheelectricalsystemofthemachine:
Disconnectthebatterycablesfromthebattery.
DisconnectthewireharnessconnectorsfromtheToroElectronicController.
DisconnectthewireharnessconnectorsfromtheengineECU.
Disconnecttheterminalconnectorfromthealternator.
Groundsmaster360
Page5–3
ElectricalSystem:GeneralInformation
16225SLRevC
