Toro Groundsmaster 360 Service Manual

SteeringSelectorManifoldAssembly
g036315
Figure149
1.Mount(2each)6.90°hydraulictting(3each)11.Washer(2each)
2.Screw7.O-ring(4each)12.Straighthydraulictting
3.Screw(2each)8.Flangenut(2each)13.Washer(2each)
4.Manifoldmountplate9.Steeringselectormanifold14.Flangenut(2each)
5.O-ring(4each)10.Screw
ThesteeringselectormanifoldassemblyusedontheGroundsmaster360
machineswith4-wheeldrivepreventssteeringoftherearwheelswhenthe
operatorpressesthesteeringselectorswitchtothe2wheelsteeringposition
(theswitchlightisilluminated).
HydraulicSystem:ServiceandRepairs
Page4–156
Groundsmaster360
16225SLRevC

Toro Groundsmaster 360 Specifications

General

Cutting Width	72 inches
Fuel Type	Diesel
Number of Blades	3
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm) - Zero Turn
Drive System	4WD
Cutting Height	1.5 - 5 inches
