Toro Groundsmaster 360 Service Manual

ServicingtheCartridgeValves
CAUTION
Beforeopeningthehydraulicsystem,operateallthehydraulic
controlstoreleasesystempressureandavoidinjuryfromthe
pressurizedhydraulicuid;refertoReleasingPressurefromthe
HydraulicSystem(page4–5).
IMPORTANT
AnoriceisthreadedintothetractionmanifoldassemblyportsOR1,
OR2,OR3,andOR4.Ifanyoriceisremovedfromtheports,ensure
tolabelitspositionforassemblypurposes.Whileassembling,
ensurethattheoriceiscorrectlyinstalled.
Forthecartridgevalveserviceprocedures;refertoServicingtheCartridge
ValvesinaControlManifold(page4–134).RefertoFigure135forCrossTrax
tractionmanifoldassemblycartridgevalveandpluginstallationtorque.
Groundsmaster360
Page4–133
HydraulicSystem:ServiceandRepairs
16225SLRevC
