Figure301(continued)
1.Backextension18.Bolt35.Rivet
52.Flangenut(6each)
2.Backcushion
19.Seatbelt36.Compressorassembly53.Screw(6each)
3.Backpanel
20.Seatwireharness
37.Retainingring54.Bracket
4.Screw21.Seatcushion38.Shockabsorber
55.Bellows
5.Handle22.Adjusterrod
39.Suspensionpivotbushing
56.Backresthandle
6.Knob
23.Spring40.Socket-headscrew
57.Backrestlever
7.Flangenut
24.Springseat
41.Band
58.Leftarmrest
8.Spring
25.Rightarmrest
42.Suspensionpivot59.Screw
9.Bushing26.Nut43.Bushing
60.Seatbaseassembly
10.Screw
27.Washer44.Bracket61.Handle
11.Bracket28.Rivet45.Bolt62.Rivet
12.Nut29.Handleassembly46.Bracket63.Extensionbracket
13.Rivet30.Lever47.Nut64.Washer
14.Rightcover31.Pin
48.Suspensionassembly65.Clip
15.Leftcover32.Spring49.Screw
16.Nut33.Torxscrew50.Rightseatadjuster
17.Seatbeltlatch
34.Airspringassembly
51.Leftseatadjuster
Note:RefertoyourPartsCatalogfortheoperatorseatcomponentsthatare
available.
DisassemblingtheOperatorSeat
1.Ifnecessary,removetheoperatorseatfromthemachine;refertoRemoving
theOperatorSeat(page6–60).
2.DisassembletheoperatorseatasshowninFigure301.
AssemblingtheOperatorSeat
1.AssembletheoperatorseatasshowninFigure301.
2.Iftheoperatorseatwasremovedfromthemachine,securetheseattothe
machine;refertoInstallingtheOperatorSeat(page6–61).
Chassis:ServiceandRepairs
Page6–66
Groundsmaster360
16225SLRevC
