User’s Manual 6-6
Hardware & Options Operation
Removing the battery pack
To remove a discharged battery, follow the steps as detailed below:
1. Save your work.
2. Turn the device’s power off - ensure that the Power indicator is off.
3. Remove all cables and peripherals that are connected to the device.
4. Close the display panel and turn the device upside down.
5. Slide the battery lock into its unlock position.
6. Slide and hold the battery release latch to disengage the battery pack
and then remove it from the device.
Figure 6-1 Releasing the battery pack
Installing the battery pack
To install a battery pack, follow the steps as detailed below:
1. Insert the battery pack as far as it will go into the device.
2. Ensure that the battery pack is securely in place and the battery lock is
in its lock position.
Figure 6-2 Securing the battery pack
3. Turn your device over.
1. Battery lock 3. Battery pack
2. Battery release latch
1. Battery pack 2. Battery lock
1
2
3
1
2

Toshiba AC100 Specifications

General

Processor	NVIDIA Tegra 250
Storage	8GB or 16GB SSD
Display	10.1-inch, 1024x600 pixels
Operating System	Android 2.1
Wireless	Wi-Fi 802.11b/g/n
Bluetooth	Bluetooth 2.1 + EDR
RAM	512 MB
Battery	Up to 8 hours
Weight	870g
Ports	1 x USB 2.0, 1 x HDMI, SD card reader, Headphone/Microphone combo port
Graphics	NVIDIA GeForce
