Chiller Report
12 CVHE-CLD-1A
Chiller Operating Mode
The chiller operating modes display comes up first in
the standard report:
Line 1 (and 2 if needed) indicates a current condition
of the unit as shown in the preceding table (Table 1) .
In some cases, an associated timer or system
parameter will be displayed that assures the
transition to an expected mode is in progress,
particularly during the unit start-up sequence.
Active Chilled Water Setpoint/Evap
Leaving Water Temp
If the chiller is in the Ice Making or Ice Making
Complete state, the following display is substituted
for the above display:
If the chiller is in the hot water control state, the
following display is substituted for the above display:
Active Chilled Water Setpoint/Chilled
Water Setpoint Source
Settings source will be one of the following: Front
Panel, Tracer, External Source, or Duplex Control.
Active Ice Termination Setpoint/Ice
Termination Setpoint Source
The following will be displayed only if the Ice Building
Option is installed.
Settings source will be one of the following: Front
Panel or Tracer.
Active Hot Wtr Setpoint/Hot Wtr Setpoint
Source
The following will be displayed only if the Hot Water
Control Option is Installed.
Settings source will be one of the following: Front
Panel, Tracer, or External Source.
[Operating mode line 1]
[Operating mode line 2]
Active Chilled Water Setpoint:xxx.x f/c
Evap Leaving Water Temp: xxx.x f/c
Active Ice Termination Setpoint: xxx.x f/c
Evap Entering Water Temp: xxx.x f/c
Active Hot Water Setpoint: xxx.x f/c
Cond Leaving Water Temp: xxx.x f/c
Active Chilled Water Setpoint: xxx.x f/c
[settings source]CWS: xxx.x f/c
Active Ice Termination Setpoint: xxx.x f/c
[settings source] ITS: xxx.x f/c
Active Hot Water Setpoint: xxx.x f/c
[settings source] HWS: xxx.x f/c
