Trane CVHG Information Manual

88 CVHE-CLD-1A
FastPak™ “Settings Group” Menu Record
Service Tests Group:
Menu item Choices Default Design/Actual
1 Chilled Water Pump Auto, On Auto
2 Condenser Water Pump Auto, On Auto
5 Starter Dry Run: (Starter Dry Run Contactor
Test - Y - D Only)
(Not available on any
FastPak models)
Disabled
6 Oil Pump (Set to Differential Transducer) Auto, On Auto
7 Oil Pump (Set to Differential Switch) Auto, On Auto
Vane Control Status Vane Position
Commands (Displayed when “Inlet Guide
Vane Output” is set to “Stepper Motor”.)
Manual, Auto Auto
8 Vane Control Status Vane Position
Commands (Displayed when “Inlet Guide
Vane Output” is set to “Pulsed”.)
Auto, Hold, Load, Unload Auto
9 Manual Loading/Unloading Duty Cycle 0 to 50% 30%
10 HGBP Valve Control is Auto, Open, Close Auto
11 HGBP Valve Opening /Closing Duty Cycle
(Displayed when “Inlet Guide Vane Output”
is set to “Pulsed”.)
0 to 50% 30%
