Diagnostics Menu
64 CVHE-CLD-1A
Diagnostics
In the table following, a “Latching” diagnostic is a
condition which will cause the machine or a portion of
the machine as noted to shut down and will require a
manual reset to restore operation. A diagnostic that
is non-latching is reset automatically when the
condition causing the diagnostic goes away. A non-
latching diagnostic will shut down the machine or a
part of the machine if so indicated. If a diagnostic is
information only, no machine action is taken.
Unless otherwise stated, all active diagnostics will be
lost on loss of power.
Diagnostic Types And Action
MMR = Machine Shutdown - Manual Reset
MAR = Machine Shutdown - Auto Reset
IFW = Information Warning - May affect machine
operation; lowest level of diagnostic
Remotely Resettable Diagnostics:
Except for the following, all diagnostics can be reset
remotely from either the Remote Clear Language
Display, the Tracer, or the External Diagnostic Reset
input at the Options Module. The following
diagnostics shall only be resettable ONLY at the
Local Clear Language Display, e.g. with the operator
standing at the unit.
Table 5
DIAGNOSTIC DESCRIPTION
Diag
Type
Can Be
Remotely
Reset DIAGNOSTIC DESCRIPTION
Diag
Type
Can Be
Remotely
Reset
Starter Contactor Interrupt Failure MMR No
Low Evap Rfgt Pressure MMR No
Phase Loss MMR No
Phase Reversal MMR No
High Bearing #1 Temp MMR No High Motor Temp Position #3 MMR No
High Bearing #2 Temp MMR No Severe Phase Unbalance MMR No
Current Overload MMR No Starter Fault Type I MMR No
Cprsr did not Accelerate: Shutdown MMR No
Starter did not Transition MMR No Starter Fault Type II MMR No
High Pressure Cutout Tripped MMR No Starter Fault Type III MMR No
Low Evap Rfgt Temp. MMR No Cprsr did not Accelerate Fully MMR No
Emergency Stop Input MMR No High Cprsr Discharge Temp. MMR No
Starter Dry Run Test MMR No Phase Seq Monitor: Phase Reversal MMR No
Solid State Starter Fault Rly Open MMR No Transition Complete Input Shorted MMR No
Adapt Freq Drive Fault Relay Open MMR No At Speed Input Shorted MMR No
High Motor Temp Position #1 MMR No Transition Complete Input Opened MMR No
High Motor Temp Position #2 MMR No At Speed Input Opened MMR No
