Field Start-up

38 CVHE-CLD-1A

Note: On Non-Adaptive Frequency chillers this Timer

times out when the chiller is at minimum IGV position

and the Leaving Water Temp is below the CWS. On

Adaptive Frequency chillers this Timer times out

when the chiller is at minimum IGV position or

minimum AF speed and LWT < CWS.

Time Permitted at Minimum Capacity

The following will be displayed only if the Minimum

Capacity Timer setpoint is Enabled.

Range of values is 1 to 480 minutes in increments of

1 Minute. Factory Default is 30 Minutes.

Evaporator Flow Coefficient

The following is displayed only if the Differential

Water Press Sensor Option is Installed.

Range of values is 0 to 3000 in increments of 5.

Factory Default is 1000.

Evaporator Flow Equation Exponent

The following is displayed only if the Differential

Water Press Sensor Option is Installed.

Range of values is 0 to 1000 in increments of 1.

Factory Default is 600.

Note: The desired range for the above is 0.5000 to

0.6000. To put in this kind of range into the CLD, the

fact that it does not start at zero represents a special

case. To minimize special cases it is preferred that a

multiplier of 10,000 and a offset of 5000 be used in

the computer that generates the number.

Evaporator Fluid Coefficient

The following is displayed only if the Differential

Water Press Sensor Option is Installed.

Range of values is 0 to 1000 in increments of 1.

Factory Default is 400.

Note: The desired range for the above is 0.0000 to

0.1000. To put in this kind of range into the CLD, the

fact that it does not start at zero represents a special

case. To minimize special cases it is preferred that a

multiplier of 10,000 be used in the computer that

generates the number.

Condenser Flow Coefficient

The following is displayed only if the Differential

Water Press Sensor Option is Installed.

Range of values is 0 to 2000 in increments of 5.

Factory Default is 500.

Condenser Flow Equation Exponent

The following is displayed only if the Differential

Water Press Sensor Option is Installed.

Range of values is 0 to 1000 in increments of 1.

Factory Default is 600.

Note: The desired range for the above is 0.5000 to

0.6000. To put in this kind of range into the CLD, the

fact that it does not start at zero represents a special

case. To minimize special cases it is preferred that a

multiplier of 10,000 and a offset of 5000 be used in

the computer that generates the number.

Time Permitted at Min Cap: xxx Min
