Trane CVHG Information Manual

86 CVHE-CLD-1A
FastPak™ “Settings Group” Menu Record
Machine Configuration Group:
Menu Item Choices Default Design/Actual
31 Printer Option Installed, Not Installed Not Installed
32 Duplex Control Module
(DCM) Option
Installed, Not Installed Not Installed
33 IGV Output Type Stepper Motor, Pulsed Stepper Motor
34 Oil Pressure Protection Xducer; Diff Switch Xducer
35 Programmable Analog
Output
Not Used;% RLA;% Cond
Press; Refrig Diff Press
% RLA
36 Program Relay [N] where [N]
= 1, 2 or 3
Not Used; Comp Running;
MMR Alarm; MAR Alarm;
MMR + MAR Alarm; Limit
Warning; Ice Making; Head
Relief Request; Tracer
Controlled; Max Capacity
1 = MMR + MAR Alarm
2 = Comp Running
3 = Not Used
37 Current Transducer Cutler Hammer, Other Cutler Hammer
38 Current Transducer at 100%
RLA (Displayed only if
Current Transducer is set to
“Other’)
-10.0 to -5.0 VDC in 0.1 VDC
Increments
39 Outdoor Air Temp Sensor Installed, Not Installed Installed

Trane CVHG Specifications

General

Brand	Trane
Model	CVHG
Category	Chiller
Language	English
