ASHRAE Guideline 3 Report
4 CVHE-CLD-1A
ASHRAE Guideline 3 Report
If <Enter> is pressed the ASHRAE Guideline 3
Report Menu is entered, shown at the end of the
Standard Report below. Otherwise, If <Next> is
pressed the Standard Report is entered. The
ASHRAE Guideline 3 Report Entry screen may be
added to Custom Report by pressing the <+> key.
Adding it to the Custom Report allows the user to
access the ASHRAE Guideline 3 Report from the
Custom Menu.
The following are the Standard Report screens, e.g.
not part of the ASHRAE Guideline 3 Report.
ASHRAE Guideline 3 Reports
Time Of Day/Refrigerant Type
Possible values for refrigerant type are: R11, R123,
R12, R134a, R22, R113, R114, R500, or R502.
Chiller Operating Mode
The chiller operating modes display comes up first in
the standard report:
Line 1 (and 2 if needed) indicates a current condition
of the unit as shown in the following table (Table 1) .
In some cases, an associated timer or system
parameter will be displayed that assures the
transition to an expected mode is in progress,
particularly during the unit start-up sequence.
Press (Enter) For ASHRAE Guideline 3 Rpt
Press (Next)(Previous) To Continue
ASHRAE Guideline 3 Report
Press (Next)(Previous) To Continue
Current Time/Date HH:MM xm Mon,XX XXXX
Refrigerant Type: [type]
[Operating mode line 1]
[Operating mode line 2]
