Trane CVHG Information Manual

Information Manual 85
FastPak™ “Settings Group” Menu Record
Machine Configuration Group:
Menu Item Choices Default Design/Actual
1 Unit Frequency 60 HZ, 50 HZ 60 HZ
2 Unit Type CVHE & CVHG, CVHF, CVHB,
CVGE, CVAE, FastPak Water
Cooled, FastPak Air Cooled
CVHE
3 Nominal Unit Tons 100 to 1800 Tons 300 Tons
4 Refrigerant Type R114, R500, R502 R123
5 Refrigerant Monitor Type None, PC None
6 Starter Type Undefined, Adaptive Frequency, Y-
Delta, X-Line, Solid State, Auto,
Transformer, Primary Reactor,
AFDB, SMCDP, Stand Alone No Str
Module
Y-Delta
7 Level 2 Contactor Integrity Test (Startup
Contactor Test-Y-D only)
Disable, Enable (Not available on
any FastPak models)
Disable
8 Rated Load Amps 0 to 2,500 500
9 Motor Heating Constant 0 to 100 Minutes 25 Minutes
10 Current Overload Setting #1
(See Manual for Setup Procedure)
00 to 31 00
11 Current Overload Setting # 2 (See Manual
for Setup Procedure)
224 to 255 255
12 Maximum Accel Time Setpt# 1 (See
Manual for Recommend Setpt)
6 to 64 Seconds 27 Seconds
13 (255 Minus Timer Setpt #1 above) 191 to 249 Seconds 226 Seconds
14 Heatsink Start Inhibit Temperature Setpoint 100.0 to 200.0 °F (37.8 to 93.3 °C),
in increments of 0.1 °F/°C
100 °F (93.3°C)
15 External Chilled Wtr Setpoint Installed, Not Installed Not Installed
16 External Current Limit Setpt Installed, Not Installed Not Installed
17 Acceleration Time Out Action Shutdown, Transition Shutdown
18 Motor Temp Protection 3 Winding Sensors, MTC Switch 3 Winding
Sensors
19 Motor Winding RTD Type 100 Ohm/ 0°C, 75 Ohm/ 75°C 75 Ohm /75°C
20 High Pressure Cutout setting -5 to 500 PSIG 15 PSIG for
standard unit 25
PSIG for ASME
unit
21 Line Voltage Sensing Option Installed, Not Installed Not Installed
22 Unit Line Voltage 180 to 6600 460
23 Hot Gas Bypass Option Installed, Not Installed Not Installed
24 Condenser Press. Sensor Option Installed, Not Installed Not installed
25 Bearing Temp Sensors Option Installed, Not Installed Not installed
26 Discharge Temp Sensor Option Installed, Not Installed Not installed
27 Ice Building Option Installed, Not Installed Not installed
28 External Analog Inputs 4-20 mA, 2-10 VDC 4-20 mA
29 Tracer Option Installed, Not Installed Not Installed
30 TCI Option Installed, Not Installed Not Installed
