Machine Configuration
Information Manual 45
Table 4
CT Factor, Current Overload Settings #1 and #2
Maximum Acceleration Timer #1
The range of values is 6 to 64 seconds. Factory
default is 27 seconds.
Maximum Acceleration Timer #2
The maximum acceleration timers establish the
starting overcurrent protection.
The range of values is 191 to 249 Sec. Factory
Default is 228 Seconds. For security purposes the
second setting is the 8-bit one's complement of the
Timer #1 setting above. Both the Maximum Accel.
Timers and the Overload Settings are not adjustable
from either the Remote CLD or Tracer or any other
Remote/External Device.
Hot Water Control Option
This screen does not appear if compressor power
source is “Engine/Generator.”
Possible values for status are: Installed and Not
Installed (Factory Default).
Heatsink Start Inhibit Temperature
Setpoint (FastPak)
The range of values shall be 100.0 to 200.0 °F (37.8
to 93.3 °C) in increments of .1°F/°C. Default shall be
100 °F (93.3 °C).
CT
Factor
Current
Overload
Setting #1
Current
Overload
Setting #2
CT
Factor
Current
Overload
Setting #1
Current
Overload
Setting #2
CT
Factor
Current
Overload
Setting #1
Current
Overload
Setting #2
66 00 255 77 11 244 88 22 233
67 01 254 78 12 243 89 23 232
68 02 253 79 14 241 90 24 231
69 03 252 80 15 240 91 25 230
70 04 251 81 16 239 92 25 230
71 06 249 82 17 238 93 26 229
72 06 248 83 18 237 94 27 228
73 07 248 84 19 236 95 28 227
74 08 247 85 20 235 96 28 227
75 09 246 86 21 234 97 29 226
76 10 245 87 22 233 98 30 225
99 30 225
Maximum Accel Timer Setpt #1: xx Sec
Press (+)(-) to Change Setting
Starter Type
Recommended Max. Accel.
Timer #1 Setting
Undefined Contact Factory
Variable Speed 20
Y-Delta 27 (Factory Default)
X-Line 6
Sold State 20
Auto-transformer 16
Primary Reactor 11
Maximum Accel Timer Setpt #2: xx Sec
Press (+)(-) to Change Setting
Hot Water Control Option: [status]
Press (+)(-) to Change Setting
Heatsink Start Inhibit Temp: xxx.x f/c
Press <+> <-> To Change Setting
To Next Page
