Chiller Report
Information Manual 13
Evaporator Entering and Leaving Water
Temperatures
Cond Entering and Leaving Water Temps
Dashes will be displayed for condenser entering or
leaving water temperature if the corresponding input
is open or shorted.
Active Current Limit Setpoint
Active Current Limit Setpoint/Current
Limit Setpoint Source
Settings source will be one of the following: Front
Panel, Tracer, External Source, or Ice Building.
Evaporator Water Flow/ Condenser
Water Flow
The following will be displayed only if the Differential
Water Sensing Option is installed.
The possible values for units are “gpm” or “lpm.”
Chiller Tons
The following will be displayed only if the Differential
Water Sensing Option is installed.
The possible values for units are “Tons” or “KW.”
Outdoor Temperature
If the outdoor air temperature input is open or
shorted and neither Outdoor Air Reset nor Low
Ambient Lockout is enabled, display “------” in place
of “xxx.x F.” Otherwise the temperature received
from the chiller module is displayed.
Aux. Bundle or Heat Recovery Temps
The following will be displayed only if either the Heat
Recovery Option or Aux Condenser Option is
installed.
Chilled Water Setpoint Source
Settings source will be one of the following: Front
Panel, Tracer, or External Source.
Reset condition will be one of the following: None,
Outdoor Temp, or Return Wtr Temp.
Evap Entering Water Temp: xxx.x f/c
Evap Leaving Water Temp: xxx.x f/c
Cond Entering Water Temp: xxx.x f/c
Cond Leaving Water Temp: xxx.x f/c
Active Current Limit Setpoint: xxx %
Press (Next)(Previous) To Continue
Active Current Limit Setpoint: xxx %
[settings source] CLS: xxx %
Approx Evaporator Water Flow:xxx.x gpm/lpm
Approx Condenser Water Flow: xxx.x gpm/lpm
Approximate Chiller Capacity: xxxx Tons/KW
Press (Next)(Previous) To Continue
Outdoor Air Temperature: xxx.x f/c
Press (Next)(Previous) To Continue
Aux/Heat Rcvy Ent Wtr Temp: xxx.x f/c
Aux/Heat Rcvy Lvg Wtr Temp: xxx.x f/c
Chld Wtr Setpt Source: [settings source]
Reset Condition: [reset condition]
To Next Page
