Field Start-up
Information Manual 37
Intercept
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator.
Range of values is 0.01 to 2.00 in increments of 0.01.
Factory Default is 0.40. This setpoint is settable from
this screen but also changes as the Adjustable
Frequency Control Algorithm runs. It is similar to a
clock setting where you set it and then it runs from
there.
AF Boundary Pressure Coefficient Y
Intercept Max
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator.
Range of values is 0.01 to 2.00 in increments of 0.01.
Factory Default is 2.00.
AF Pressure Error Deadband
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator.
Range of values is 0.001 to 1.000 in increments of
0.001. Factory Default is 0.030.
AF Proportional Speed Gain
The following is displayed only if the Starter Type is
“Adaptive Frequency” or “AFDB” or the Compressor
Power Source is Engine/Generator.
Range of values is 1 to 100 in increments of 1.
Factory Default is 50.
Minimum Capacity Timer Enable
The choices for Status are: Enable (Factory Default)
and Disable (Unlmtd Time).
AF Boundary PC Y-Intercept: x.xx
Press (+)(-) to Change Setting
AF Boundary PC Y-Intercept Maximum: x.xx
Press (+)(-) to Change Setting
AF Pressure Error Deadband: x.xxx
Press (+)(-) to Change Setting
AF Proportional Speed Gain: xxx
Press (+)(-) to Change Setting
Min Capacity Timer: [Status]
Press (+)(-) to Change Setting
To Next Page
