Table 7. Circuit-level operating modes and corresponding submodes for Duplex chillers (continued)
Top-level mode Description Corresponding submodes
Running The compressor on the circuit is currently running.
Surge
Hot Gas Bypass
Current Limit
Phase Unbalance Limit
Evaporator Temperature Limit
High Compressor Discharge Temp Limit
Running—Limit Compressor is running with limits in effect.
Current Limit
Phase Unbalance Limit
Condenser Pressure Limit
Evaporator Temperature Limit
High Compressor Discharge Temp Limit
Preparing to Shutdown The circuit is preparing to de-energize the compressor. Closing IGV
(b)
Shutting Down
The chiller is going through the necessary steps after de-
energizing the compressor.
Post-Lubrication Time (MIN:SEC)
(a)
Miscellaneous
These submodes may appear with most of the top-level chiller
modes.
Overdrive IGV Closed
(b)
Oil Pump Override
(a)
“MIN:SEC” refers to a count-down timer that appears on the screen to indicate how long the submode will remain active.
(b)
“IGV Position %” refers to a value that indicates the position of the inlet guide vane (IGV).
Purge Operating Modes
On the Reports screen, touch PPuurrggee OOppeerraattiinngg MMooddeess to view the current operating status of
the purge system in terms of the top-level operating mode and submodes.
NNoottee:: For Duplex™ chillers, the operating status of purge system is shown in terms of the two
circuits.
The purge system operates in one of four top-level operating modes:
• Stop
• On
• Auto
• Adaptive
Submodes are dependent on the top-level mode. Their appearance on the Purge Operating
Modes screen has the following characteristics:
• The newest submode appears at the top of the submode list.
• Submodes disappear when they no longer apply.
• The screen displays up to six submodes.
• If less than six submodes are active, the submode rows that do not apply are blank.
For detailed information about purge operating modes and submodes, refer to PRGF-SVX001*-
EN (Installation, Operation, and Maintenance: EarthWise Purge System with Tracer AdaptiView
Control for Water-cooled CenTraVac Chillers with R-123 Refrigerant) or PRGG-SVX001*-EN
(Installation, Operation, and Maintenance: Purge System with Tracer AdaptiView Control for
Water-cooled CenTraVac Chillers with R-514A Refrigerant), as appropriate.
