Trane Tracer AdaptiView User Manual

CTV-SVU01G-EN
65
Table 20. Purge settings and status points (Simplex) (continued)
Daily Pumpout Limit/Alarm Pumpout—Life
Chiller On—7 Days Purge Carbon Tank Temp
Reports
The following data can be viewed on the Reports screen. For more information, refer to
“Reports,” p. 23.
Log Sheet
Table 21. Evaporator report data
Report item
Unit
Evaporator Entering Water Temperature
XXX.X °F/°C
Evaporator Leaving Water Temp
XXX.X °F/°C
Evaporator Sat Rfgt Temp
XXX.X °F/°C
Evaporator Rfgt Pressure
XXX.X PSI/kPa
Evaporator Approach Temp
XXX.X °F/°C
Evaporator Water Flow Switch Status
Flow/No Flow
Table 22. Condenser report data
Report item
Unit
Cond Entering Water Temp
XXX.X °F/°C
Cond Leaving Water Temp
XXX.X °F/°C
Cond Sat Rfgt Temp
XXX.X °F/°C
Cond Rfgt Pressure
XXX.X PSI/kPa
Cond Approach Temp
XXX.X °F/°C
Cond Water Flow Switch Status
Flow/No Flow
Cond Rfgt Liquid Level
XX.XX in/mm
Table 23. Compressor report data
Report item
Unit
Starts XXXX Starts
Running Time
XX:XX Hr:Min
Oil Tank Pressure
XXX.X PSI/kPa
Oil Pump Discharge Pressure
XXX.X PSI/kPa
Oil Differential Pressure
XXX.X PSI/kPa
Oil Tank Temperature
XXX.X °F/°C
IGV 1 Position XXX.X %
Oil Diff Pressure Switch (CVGF, CVR)
XXX.X PSI/kPa
Lube Pump Discharge Pressure (CVHS)
XXX.X PSI/kPa
Cond Rfgt Pressure (visible only with CVHS)
XXX.X PSI/kPa
IGV 1 Position
Steps
AAppppeennddiixx AA:: DDaattaa ffoorr CCeennTTrraaVVaacc SSiimmpplleexx CChhiilllleerrss
