Trane Tracer AdaptiView User Manual

CTV-SVU01G-EN
79
Log Sheet
Table 54. Evaporator
Report item
Unit
Evaporator Entering Water Temperature
XXX.X °F/°C
Evaporator Leaving Water Temp
XXX.X °F/°C
Evaporator Water Flow Status
Flow/No Flow
Evaporator Sat Rfgt Temp (Ckt1 and Ckt2)
XXX.X °F/°C
Evaporator Rfgt Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Evaporator Approach Temp (Ckt1 and Ckt2)
XXX.X °F/°C
Table 55. Condenser
Report item
Unit
Cond Entering Water Temp Cond Entering Water Temp
Cond Leaving Water Temp Cond Leaving Water Temp
Cond Water Flow Status Cond Water Flow Status
Cond Sat Rfgt Temp (Ckt1 and Ckt2) Cond Sat Rfgt Temp (Ckt1 and Ckt2)
Cond Rfgt Pressure (Ckt1 and Ckt2) Cond Rfgt Pressure (Ckt1 and Ckt2)
Cond Approach Temp (Ckt1 and Ckt2) Cond Approach Temp (Ckt1 and Ckt2)
Table 56. Motor
Report item
Unit
Starter Current L1 %RLA (Ckt1 and Ckt2)
XXX.X %
Starter Current L2 %RLA (Ckt1 and Ckt2)
XXX.X %
Compressor Starts (Ckt1 and Ckt2)
XXXX Starts
Compressor Running Time (Ckt1 and Ckt2)
XX:XX Hr:Min
Oil Tank Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Oil Pump Discharge Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Oil Differential Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Oil Tank Temperature (Ckt1 and Ckt2)
XXX.X °F/°C
IGV 1 Percent Open (Ckt1 and Ckt2)
XXX.X %
IGV 1 Position (Ckt1 and Ckt2) Steps
IGV 2 Percent Open (Ckt1 and Ckt2)
XXX.X %
IGV 2 Position (Ckt1 and Ckt2) Steps
Starter Current L3 %RLA (Ckt1 and Ckt2)
XXX.X %
Starter Current L1 (Ckt1 and Ckt2)
XXXX A
Starter Current L2 (Ckt1 and Ckt2)
XXXX A
Starter Current L3 (Ckt1 and Ckt2)
XXXX A
Starter Voltage Phase AB (Ckt1 and Ckt2)
XXXXX.X V
Starter Voltage Phase BC (Ckt1 and Ckt2)
XXXXX.X V
Starter Voltage Phase CA (Ckt1 and Ckt2)
XXXXX.X V
AAppppeennddiixx BB:: DDaattaa ffoorr CCeennTTrraaVVaacc DDuupplleexx CChhiilllleerrss
