Table 74. Purge (continued)
Graph data point
Axis
Average Daily Pumpout—7 Days (Ckt1 and Ckt2) Right Y-axis
Purge Refrigerant Compressor Suction Temperature (Ckt1 and Ckt2) Right Y-axis
Purge Liquid Temperature (Ckt1 and Ckt2) Right Y-axis
Table 75. Approach Temperature
Graph data point
Axis
Evaporator Approach Temperature (Ckt1 and Ckt2)
Left Y-axis
Condenser Approach Temperature (Ckt1 and Ckt2)
Left Y-axis
Approximate Evaporator Water Flow (Ckt1 and Ckt2) Right Y-axis
Approximate Condenser Water Flow (Ckt1 and Ckt2) Right Y-axis
Average Line Current %RLA (Ckt1 and Ckt2) Right Y-axis
Data Points in Custom Data Graphs
Table 76. Evaporator
Active Chilled Water Setpoint
Evaporator Leaving Water Temperature
Evaporator Entering Water Temperature
Approx Evap Water Flow
Evap Differential Wtr Press
Calculated Chiller Capacity
Active Ice Termination Setpoint
Evaporator Saturated Rfgt Temp Ckt1
Evaporator Refrigerant Pressure Ckt1
Evaporator Approach Temperature Ckt1
Evaporator Saturated Rfgt Temp Ckt2
Evaporator Refrigerant Pressure Ckt2
Evaporator Approach Temperature Ckt2
Evaporator Entering Water Pressure
Evaporator Leaving Water Pressure
Table 77. Condenser
Active Hot Water Setpoint
Condenser Leaving Water Temperature
Condenser Entering Water Temperature
Outdoor Air Temperature
Refrigerant Monitor
Approx Cond Water Flow
