CTV-SVU01G-EN
63
Appendix A: Data for CenTraVac Simplex Chillers
The following lists contain all of the data available for viewing on a Tracer® AdaptiView™
display that is connected to a CenTraVac™ Simplex chiller.
Component Screen Data
Chiller configuration determines which of the following settings and status points appear on the
display. For more information, refer to “Component Screens,” p. 14.
Table 16. Evaporator settings and status points (Simplex)
Active Chilled Water Setpoint (button links to the Active Chiller Water
Setpoint screen)
Evaporator Rfgt Pressure
Evaporator Pump Override (button links to Evaporator Pump Override
screen)
Evap Approach Temp
Evap Water Flow Status Approx Evap Water Flow
Evap Leaving Water Temp Evap Differential Wtr Press
Evap Entering Water Temp Evaporator Entering Water Pressure
Calculated Chiller Capacity Evaporator Leaving Water Pressure
Evaporated Saturated Rfgt Temp
Table 17. Condenser settings and status points (Simplex)
Active Hot Water Setpoint (button links to the Active Hot Water
Setpoint screen)
Approx Cond Water Flow
Cond Condenser Pump Override (button links to the Condenser Pump
Override screen)
Cond Differential Wtr Press
Cond Water Flow Status
Second Condenser Lvg Wtr Temp
Cond Entering Water Temp Second Condenser Ent Wtr Temp
Cond Leaving Water Temp
Head Pressure Control Status
Outdoor Air Temp Differential Refrigerant Pressure
Condenser Sat Rfgt Temp Refrigerant Monitor
Condenser Refrigerant Pressure Condenser Entering Water Pressure
Condenser Refrigerant Liquid Level Condenser Leaving Water Pressure
Condenser Approach Temperature Economizer Bypass Valve Position
Table 18. Compressor settings and status points (Simplex)
Compressor Running Status IGV 2 Percent Open
Chiller Control Signal IGV 2 Position (Steps)
Oil Pump Control Compressor Rfgt Discharge Temp
Average Line Current (%RLA)
HGBP Time
Oil Pump Status Oil Differential Pressure Switch (CVG, CVR Only)
Oil Differential Pressure
Lube Differential Pressure (CVHS Only)
Compressor Starts Lube Pump Discharge Pressure (CVHS Only)
Compressor Running Time Lube Pump Suction Pressure (CVHS)
Oil Pump Discharge Pressure Cond Rfgt Pressure
