Trane Tracer AdaptiView User Manual

CTV-SVU01G-EN
77
Appendix B: Data for CenTraVac Duplex Chillers
The following lists contain all of the data available for viewing on a Tracer® AdaptiView™
display that is connected to a CenTraVac™ Duplex™ chiller.
Component Screen Data
Chiller configuration determines which of the following settings and status points appear on the
display. For more information, refer to “Component Screens,” p. 14.
Table 49. Evaporator settings and status points
Active Chilled Water Setpoint (button links to the Active Chiller Water
Setpoint screen)
Evaporator Rfgt Pressure (Ckt1 and Ckt2)
Evaporator Pump Override (button links to Evaporator Pump Override
screen)
Evap Approach Temp (Ckt1 and Ckt2)
Evap Water Flow Status Approx Evap Water Flow
Evap Leaving Water Temp Evap Differential Wtr Press
Evap Entering Water Temp Evap Entering Water Press
Calculated Chiller Capacity Evap Leaving Water Press
Evaporator Saturated Rfgt Temp (Ckt1 and Ckt2)
Table 50. Condenser settings and status points
Active Hot Water Setpoint (button links to the Active Hot Water
Setpoint screen)
Condenser Approach Temperature (Ckt1 and Ckt2)
Condenser Pump Override (button links to the Condenser Pump
Override screen)
Approx Cond Water Flow
Cond Water Flow Status Cond Differential Wtr Press
Cond Entering Water Temp Second Condenser Lvg Wtr Temp
Cond Leaving Water Temp Second Condenser Ent Wtr Temp
Outdoor Air Temp Cond Entering Water Press
Condenser Refrigerant Pressure (Ckt1 and Ckt2) Cond Leaving Water Press
Table 51. Compressor settings and status points
Compressor Running (Ckt1 and Ckt2) Inboard Bearing Temperature (Ckt1 and Ckt2)
Chiller Control Signal Outboard Bearing Temperature (Ckt1 and Ckt2)
Oil Pump Control (Ckt1 and Ckt2) IGV 1 Percent Open (Ckt1 and Ckt2)
Average Motor Current %RLA (Ckt1 and Ckt2) IGV 1 Position (Steps) (Ckt1 and Ckt2)
Compressor Starts (Ckt1 and Ckt2) IGV 2 Percent Open (Ckt1 and Ckt2)
Oil Pump Status (Ckt1 and Ckt2) IGV 2 Position (Steps) (Ckt1 and Ckt2)
Oil Differential Pressure (Ckt1 and Ckt2) Compressor Rfgt Discharge Temp (Ckt1 and Ckt2)
Compressor Running Time (Ckt1 and Ckt2) Outboard Bearing Pad Temperature #1 CktX (for CDHH)
Oil Pump Discharge Pressure (Ckt1 and Ckt2) Outboard Bearing Pad Temperature #2 CktX (for CDHH)
Oil Tank Pressure (Ckt1 and Ckt2) Outboard Bearing Pad Temperature #3 CktX (for CDHH)
Oil Tank Temperature (Ckt1 and Ckt2)
