Serial Numbers
SERIAL NUMBERS
Vehicle Identification
Number (VIN)
1. VIN number stamping
1. V I N p l a t e l o c a t i o n
The vehicle identification number is stamped
into the steering head.
It is also displayed on a plate, riveted to the
frame, immediately behind the steering head
on the left hand side of the motorcycle.
Engine Serial Number
1. Engine serial number
The engine serial number is stamped on the
crankcase, immediately above the drive chain
sprocket cover.
Record the vehicle identification number in
the space below.
Record the engine serial number in the space
below.
cebr
1
1
ccil
1

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
