Triumph Speedmaster User Manual

57
Maintenance and Adjustment
Engine Oil
1. Filler
2. Sight glass
3. Oil level (correct level shown)
4. Crankcase oil level lines
In order for the engine, transmission, and
clutch to function correctly, maintain the
engine oil at the correct level, and change the
oil and oil filter in accordance with scheduled
maintenance requirements.
T908027
1
2
3
4
Warning
Motorcycle operation with insufficient,
deteriorated, or contaminated engine oil
will cause accelerated engine wear and
may result in engine or transmission
seizure. Seizure of the engine or
transmission may lead to loss of control
and an accident.

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
