Triumph Speedmaster User Manual

31
General Information
Side Cover: Right Hand Side
Cover
Under normal circumstances, it is not
necessary to remove the right hand side
cover from the America and Speedmaster
models, except for major service or repair
work, which must be carried out by an
authorised Triumph dealer.
Seat
Seat Care
To prevent damage to the seat cover, care
must be taken not to drop or lean the seat
against any surface which may damage the
seat or seat cover.
Seat - Speedmaster
1. S e a t
2. Fastener
3. Lock release
Caution
To prevent damage to the seat or seat
cover, care must be taken not to drop the
seat. Do not lean the seat against the
motorcycle or any surface which may
damage the seat or seat cover. Instead,
place the seat, with the seat cover facing
upwards, on a clean, flat surface which is
covered with a soft cloth.
Do not place any item on the seat which
may cause damage or staining to the seat
cover.
1
2
3

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
