Triumph Speedmaster User Manual

87
Maintenance and Adjustment
Rear Light/Licence Plate
Light
1. Rear light lens screws
2. Bulb
Bulb Replacement
• Release the screws securing the rear
light lens.
• Remove the lens.
• The bulb is a bayonet type. To
remove the bulb, gently press
inwards and twist anti-clockwise.
• Installation is the reversal of removal.
Direction Indicator Lights
1. Indicator lens screw
2. Bulb
Bulb Replacement
• The lens on each indicator light is
held in place by screws.
• Release the screws and remove the
lens to gain access to the bulb for
replacement.
T908050USA
2
1
T908051USA
1
2

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
