Triumph Speedmaster User Manual

72
Maintenance and Adjustment
• Refit the reservoir cap ensuring that
the diaphragm seal is correctly
positioned between the cap and
reservoir body.
• Locate the black reservoir cover,
position the assembly to the frame
and secure with the screw previously
removed. Tighten the screw to
7Nm.
Steering/Wheel Bearings
Steering Inspection
Lubricate and inspect the condition of the
headstock (steering) bearings in accordance
with scheduled maintenance requirements.
Note:
• Always inspect the wheel bearings
at the same time as the steering
bearings.
Warning
To prevent risk of injury from the
motorcycle falling during the inspection,
ensure that the motorcycle is stabilised and
secured on the support.
Do not exert extreme force against each
wheel or rock each wheel vigorously as this
may cause the motorcycle to become
unstable or cause injury by falling from its
support.
Ensure that the position of the support
block will not cause damage to the oil lines
or oil filter beneath the sump.

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
