Triumph Speedmaster User Manual

63
Maintenance and Adjustment
• Reconnect the battery, positive (red)
lead first.
• Refit the seat.
• Check that the throttle opens
smoothly, without undue force and
that it closes without sticking.
• Ride carefully to your nearest
authorised Triumph dealer and have
him check the throttle system
thoroughly before riding again.
Clutch
1. Clutch cable
The motorcycle is equipped with a
cable-operated clutch.
If the clutch lever has excessive free play, the
clutch may not disengage fully and could
then cause the engine to stall and create
difficulties when changing gear. Conversely, if
the clutch lever has insufficient free play the
clutch may not engage fully, causing clutch
slip.
Clutch lever free play must be checked in
accordance with scheduled maintenance
requirements.
Warning
Ensure that both the adjuster locknuts of
both cables are tightened, as a loose
locknut could result in a sticking throttle.
An incorrectly adjusted, sticking or stuck
throttle can lead to loss of motorcycle
control and an accident.
cbmy
1

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
