Triumph Speedmaster User Manual

73
Maintenance and Adjustment
Inspecting the Steering for
Free Play
Inspection
• Position the motorcycle on level
ground, in an upright position.
• Raise the front wheel off the ground.
• Hold the lower end of the front forks
and try to move them forward and
backward.
• If any free play can be detected, ask
your authorised Triumph dealer to
inspect and rectify any faults before
riding.
• Remove the support and place the
motorcycle on the side stand.
Wheel Bearings Inspection
If the wheel bearings in the front or rear
wheel allow play in the wheel hub, are noisy,
or if the wheel does not turn smoothly, have
your authorised Triumph dealer inspect the
wheel bearings.
The wheel bearings must be inspected at the
intervals specified in the scheduled
maintenance chart.
• Position the motorcycle on level
ground, in an upright position.
• Raise the front wheel off the ground.
• Gently rock the top of the front
wheel from side to side.
• If any free play can be detected, ask
your authorised Triumph dealer to
inspect and rectify any faults before
riding.
• Reposition the lifting device and
repeat for the rear wheel.
• Remove the support and place the
motorcycle on the side stand.
Warning
Riding the motorcycle with incorrectly
adjusted or defective steering bearings
may cause loss of motorcycle control and
an accident.
Warning
Operation with worn or damaged wheel
bearings may cause impaired handling and
instability leading to loss of motorcycle
control and an accident. If in doubt, have
the motorcycle inspected by an authorised
Triumph dealer before riding.

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
