Triumph Speedmaster User Manual

19
General Information
Instruments
America and Speedmaster
1. Speedometer
2. Odometer
3. Low fuel level indicator light
4. Engine management malfunction
indicator light (MIL)
5. Tachometer location (Speedmaster
only)
6. High beam indicator light
7. Direction indicator light
8. Neutral indicator light
9. Low oil pressure warning light
10 . R e s e t b u t t o n
11. Alarm status indicator light (alarm is
an accessory fit)
1
2
5
6
9
10
11
8
7
4
3
cekv

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
