Triumph Speedmaster User Manual

20
General Information
Speedometer
The speedometer indicates the road speed of
the motorcycle.
Odometer/Trip Meter
1. Odometer/trip meter/clock display
2. Reset button
The odometer shows the total distance that
the motorcycle has travelled.
There are two trip meters. Either trip meter
shows the distance that the motorcycle has
travelled since the meter on display was last
reset to zero.
To switch between the odometer and trip
meter display modes, press and release the
reset button until the desired display is visible.
The display will scroll through in the order:
•Odometer
• Trip meter 1
• Trip meter 2
•Clock
Trip Meter Reset
To reset either of the trip meters, select and
display the trip meter to be zeroed then press
the reset button for 2 seconds. After
2 seconds, the trip meter on display will reset
to zero.
1
2
Warning
Do not attempt to switch between
odometer and trip meter display modes or
reset the trip meter with the motorcycle in
motion as this may lead to loss of
motorcycle control and an accident.

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
