Triumph Speedmaster User Manual

75
Maintenance and Adjustment
Suggested Suspension Settings
Rear adjuster settings are counted from one
with position one being with the adjuster
turned fully anti-clockwise. There are five
adjuster positions in total. Position one gives
the minimum amount of spring pre-load.
Note:
• The details given in the table are
to be used as a guide only where
the rider and passenger each
weigh 90 kg or less. Setting
requirements should be increased
for heavier riders and passengers
according to personal preferences.
Tyres
Typical Tyre Marking
Typical Wheel Marking
Both models are equipped with tubeless
tyres, valves and wheel rims. Use only tyres
marked 'TUBELESS' and tubeless valves on
rims marked 'SUITABLE FOR TUBELESS
TYRES'.
Loading
Condition
Rear Adjuster
Position
Solo Riding - Softer 1
Solo Riding -
Standard
2
Solo Riding -
Firmer
3
Rider and
Passenger
5
T509-- 37

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
