General Information
Clock Adjustment
To set the clock, turn the ignition to the ON
position. Press and release the reset button
until the clock is visible in the display screen.
Press and hold the reset button for
4 seconds. After 4 seconds either 24 Hr or
12 Hr will be shown flashing. Press and
release the reset button to select the desired
clock display. When the correct display is
shown, do not touch the reset button until
the clock is shown with the hour display
flashing.
To reset the hour display, ensure that the
hour display is still flashing. Press the reset
button to change the setting. Each individual
button press will change the setting by one
digit. If the button is held, the display will
continuously scroll through in single digit
increments.
When the correct hour display is shown, do
not touch the reset button for 6 seconds. The
minutes display will begin to flash
automatically. The minutes display is adjusted
in the same way as for the hours.
Once both hours and minutes are correctly
set, do not touch the reset button for
6 seconds and the display will cease to flash
automatically.
1. C l o c k d i s p l a y
2. Hours read-out
3. Minutes read-out
Tachometer (Speedmaster
only)
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). On the
right side of the tachometer face is the
'red zone'. Engine rpm (r/min) in the red
zone is above maximum recommended
engine speed and is also above the range for
best performance.
Warning
Do not attempt to adjust the clock with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident.
Caution
Never allow engine rpm to enter the 'red
zone' as severe engine damage may result.
.
.
cayb
1
2
3

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
