Triumph Speedmaster User Manual

67
Maintenance and Adjustment
• Rotate the rear wheel and repeat the
chain adjustment check. Re-adjust if
necessary.
• Check the rear brake effectiveness.
Chain Wear Inspection
1. Measure across 20 links
2. Weight
• Remove the chain guard.
• Stretch the chain taut by hanging a
10 - 20 kg (20 - 40 lb) weight on the
chain.
• Measure the length of 20 links on
the straight part of the chain from
pin centre of the 1
st
pin to the centre
of the 21
st
pin. Since the chain may
wear unevenly, take measurements
at several places.
• If the length exceeds the maximum
service limit of 321 mm, the chain
must be replaced.
• Rotate the rear wheel and inspect
the drive chain for damaged rollers,
and loose pins and links.
Warning
Operation of the motorcycle with a loose
wheel spindle may result in impaired
stability and handling of the motorcycle.
This impaired stability and handling may
lead to loss of control or an accident.
cebu
2

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
