Unify OpenStage WL3 Administration Manual

TD 92930EN
13 December 2013 /Ver B
Configuration Manual
WL3 and WL3 Plus WLAN Handset
54
6. Handset Configuration
4 In the Number for automatic call after alarm field, enter the number to be called
after an alarm has been activated (optional).
5 In the ALS drop-down list, select “Yes“ to define if a ramped up Acoustic Location
Signal (ALS) sounds after pressing the alarm button.
6 In the Text indication for alarm on multiple press field or Text indication for alarm
on long press, write the text to be shown in the handset display when the push-
button is pressed. If this field is empty, the default text for long press “Test alarm”
or for multiple press “Personal alarm” is shown.
7 In the Mode for automatic call after alarm drop-down list, select one of the
following:
• Monitor - The loudspeaker is muted and the microphone is on.
• Loudspeaker - The loudspeaker is turned on.
• Ordinary - The loudspeaker is turned off.
6.9.3 Call Predefined Number without Sending Alarm
It is possible to use the push-button to automatically dial a predefined number without
sending an alarm, that is, using the alarm button only to call a predefined number. The
following example describes how to configure the push-button (alarm on long press).
The corresponding settings can also be configured for the push-button when it is
pressed twice or more (alarm on multiple press).
Example of configuration:
1 Select Alarm > Common
2 In the Number for automatic call after alarm field, enter the number to be dialed.
3 Select Alarm > Alarm on long press
4 In the Alarm type for long press drop-down list, select "Not used".
5 In the Mode for automatic call after alarm drop-down list, select one of the
following:
- Normal: the call is established as an ordinary call.
- Loudspeaking: the loudspeaker on the backside of the handset is turned on.
- Monitoring: a one-way speech channel is established, that is, the called party can
only listen to a conversation.

Information about the handset’s location can also be sent with an alarm, see 6.15
Location on page 65.
6.9.4 Test Alarm
1 Select “Alarm“.
2 Select “Multiple-press“ or “Long-press“.
3 In the Alarm type for multiple press drop-down list or Alarm type for long press
drop-down list, select “Test alarm“.
4 In the Number for automatic call after alarm field, enter the number to be called
after an alarm has been activated (optional).
5 In the ALS drop-down list, select “Yes“ to define if a ramped ALS sounds after
pressing the alarm button.
6 In the Text indication for alarm on multiple press field or Text indication for alarm
on long press, enter the text to be displayed in the handset when the alarm has
been activated.
