Removing
– Release parking brake.
Vehicles with the Highline Center Console
– Open the cover on the rear storage compartment.
– Remove the mat from the storage compartment.
– Loosen the adjusting nut -arrow- until it is possible to disen‐
gage the parking brake cable -1- from the compensator brack‐
et -2-.
Vehicles with the Basis Center Console
– Remove the mat from the rear storage compartment.
– Loosen the adjusting nut -arrow- until it is possible to disen‐
gage the parking brake cable -1- from the compensator brack‐
et -2-.
Continuation for All Vehicles
– Loosen the wheel bolts.
– Raise the vehicle.
– Remove the wheel.
– Disengage the parking brake cable -1- from the bracket -2-
and pull it out of the guide tube -3-.
– Remove the parking brake cable -1- bracket -2- on the rear
axle -3-.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
5. Axle Beam Plate (Torsion Beam) 163
