❑ Always replace if removed
❑ Self-locking
❑ Always tighten the threaded connections in curb weight position. Refer to
⇒ “10 Rear Axle Curb Weight (Multi-link Rear Suspension)”, page 182 .
Note
♦ Adjust the Torque Wrench 1332
40-200Nm - VAG1332- to 80 Nm
to tighten the nut.
♦ This tightening specification only
applies in conjunction with Insert
Tool - 18mm - T10179- .
7 - Subframe
8 - Bolt
❑ 70 Nm +180° turn
❑ Replace after removing
9 - Lower Transverse Link
❑ Removing and installing. Refer to
⇒ “12.8 Lower Transverse Link, Removing and Installing”, page 196 .
10 - Nut
❑ 70 Nm + 180° turn
❑ Always replace if removed
❑ Self-locking
❑ Always tighten the threaded connections in curb weight position. Refer to
⇒ “10 Rear Axle Curb Weight (Multi-link Rear Suspension)”, page 182 .
11 - Bolt
❑ Always replace if removed
12 - Threaded Rivet
❑ M6
13 - Expanding Rivet
14 - Stone Chip Protection
❑ Allocation. Refer to the Parts Catalog.
15 - Bolt
❑ 8 Nm
16 - Nut
❑ Self-locking
❑ Always replace if removed
❑ Always tighten the threaded connections in curb weight position. Refer to
⇒ “10 Rear Axle Curb Weight (Multi-link Rear Suspension)”, page 182 .
17 - Bolt
❑ 130 Nm + 90° turn
❑ Always replace if removed
❑ Always tighten the threaded connections in curb weight position. Refer to
⇒ “10 Rear Axle Curb Weight (Multi-link Rear Suspension)”, page 182 .
18 - Upper Transverse Link
❑ Removing and installing. Refer to
⇒ “12.7 Upper Transverse Link, Removing and Installing”, page 194 .
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
186 Rep. Gr.42 - Rear Suspension
