Perform the Following
Removing
Note
The following work steps are described for the left side of the ve‐
hicle. These work steps also apply simultaneously for right side
of vehicle.
– Remove the nut -1- and pull the coupling rod -2- out of the
stabilizer bar.
Note
Do not loosen bolt -arrow- for tie rod -3-.
– Remove the bolts -arrows- for the stabilizer bar clamp.
– Remove the stabilizer bar.
Installing
– Insert the stabilizer bar in the vehicle.
– Tighten the bolts -arrows- for stabilizer clamp uniformly.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
222 Rep. Gr.42 - Rear Suspension
