Continuation for All Vehicles
– Remove the bolts -1- and remove the footwell trim panel -2-.
– Remove the bolt -arrow- from the universal joint -1-, and then
remove the universal joint in the direction of the -arrow-.
Caution
If the universal joint is separated from the Electromechanical
steering gear, the following work cannot be performed:
♦ Switching on the ignition
♦ Turning the steering gear
♦ Turning the steering column.
These points must be observed since performing these actions
could cause irreparable damage.
– Loosen the wheel bolts.
– Raise the vehicle.
– Remove the wheel.
– Remove the lower noise insulation. Refer to ⇒ Body Exterior;
Rep. Gr. 50 ; Noise Insulation .
– Remove the exhaust system bracket from the subframe
-arrows-.
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
5. Front Suspension and Control Arm 45
