WARNING
♦There are two types of
twelve-point bolts, with
and without ribs. Distin‐
guishing characteristics.
Refer to
⇒ Fig. ““Difference Be‐
tween A Twelve-Point
Bolt with Ribs and A
Twelve-Point Bolt without
Ribs”“ , page 54
♦When installing a twelve-
point bolt, always check
what type of twelve-point
bolt is to be used.
♦Use the correct tighten‐
ing specification for the
specific bolt.
♦The tightening specifica‐
tion for a twelve-point bolt
»with« ribs is 70 Nm +
90°. Refer to
⇒ “9.1 Twelve-Point Bolt
with Ribs, Loosening and
Tightening, Drive Axle
Threaded Connection”,
page 77 for loosening
and tightening specifica‐
tions.
♦The tightening specifica‐
tion for a twelve-point bolt
»without« ribs is 200 Nm
+ 180°. Refer to
⇒ “9.2 Twelve-Point Bolt
without Ribs, Loosening
and Tightening, Drive
Axle Threaded Connec‐
tion”, page 78 for loos‐
ening and tightening
specifications.
❑ Always replace if removed
4 - Bolt
❑ 12 Nm
5 - Hex Socket Bolt
❑ 8 Nm
6 - Left Front ABS Wheel Speed Sensor - G47- / Right Front ABS Wheel Speed Sensor - G45-
❑ Before inserting the wheel speed sensor, clean the inner surface of the hole and coat with Securing
Grease - G 000 650- .
7 - Bolt
❑ 70 Nm + 90° turn
❑ Always replace if removed
The vehicle must not be resting on its wheels when tightening or loosening.
8 - Drive Axle
❑ Removing and installing. Refer to
⇒ “9.3 Drive Axle with CV Joint, Removing and Installing”, page 80 .
Jetta 2011 ➤ , Jetta 2013 ➤
Suspension, Wheels, Steering - Edition 08.2015
6. Wheel Bearing 53
